Model No.

FW-8764-2ODP

Form Factor

1U Rackmount

Platform

Processor Options

Intel Haswell 22nm Core i7/i5/i3, Pentium, Celeron, Xeon E3 1200 v3/v4.

CPU Socket

LGA1150

Chipset

Intel B85 or Z87

OS Support

Linux, Ubuntu, CentOS, pfSense, Windows All

BIOS

AMI 32MB

System Memory

Technology

DDR3 1600/1333/1066MHz

Max. Capacity

16GB

Socket

2 x SO-DIMM

Networking

Ethernet Ports

6 x Intel 82583V or 82574L GbE LAN

2 x 10 GbE SFP via Intel 82599

1 x PCIe X4 slot to support additional 2 x 10G SFP+ via Intel 82599ES(optional)

Bypass

1 pair of BYPASS(Optional)

Storage

HDD Bays

N/A

CF/SD

1 x CF socket onboard(Optional)

mSATA

1 x mSATA socket onboard

I/O Interface

Reset Button

1 x Reset Button

LED

1 x Power LED, 1 x HDD LED, 2 x Power Failure Warning LED

Power Button

1 x Power Button

Console

1 x RJ45 Console(Unusable by default)

USB

2 x USB 2.0

LCD Module

N/A

Display

1 x VGA output

Power Input

1 x AC Inlet

Expansion

PCIe

N/A

Mini-PCIe

1 x Mini PCIe (Supporting Wi-Fi and LTE)

Miscellaneous

Watchdog

Y

Internal RTC with Li Battery

Y

TPM

N/A

Cooling

Processor

1 x Bronze CPU Fan

System

2 x 4020 System Fan

Environmental Parameters

Temperature

-15~60℃

Humidity

0% ~ 95%, non condensing

Physical Dimensions

(WxHxD)

-

Weight

4.5KG

Package Dimensions

(WxHxD)

530*370*150mm

Weight

5.0KG

Power

Type/Watts

2 x 200W Internal Open Frame

Input

4A 100-127V~ or 2A 200-240V~ 47-63Hz
