1U Rackmount Network Appliance with Intel Core i3/i5/i7 or X
1U Rackmount Network Appliance with Intel Core i3/i5/i7 or Xeon E3 1200 v3/v4 processors, 4 x 10 GbE SFP, mSATA
Thank you for choosing the FWA-8781-4O . The system is powered by Intel Core Processors, with the Intel H87 Chipset. It supports up to 16GB of DDR3. The FWA-8781-4O is equipped with advanced I/O capacity which includes an RJ-45 console port, 2 x USB 2.0 headers, supports SSD, SATA HDD storage.
The onboard Ethernet ports be configured with bypass depending on the module specification.
The onboard Ethernet ports be configured with bypass depending on the module specification.
Supports LGA1150 Xeon/Core i3/i5/i7 Pentium/Celeron processors
Deploy Intel Intel H87 express chipset
Supports 2 x DDRIII SO DIMM memory, Max. 16GB
Integrated with 8*Intel 82574L GbE Ethernet cards, supports Wake On LAN, PXE booting
Supports 4 x GbE/10GbE SFP(optional)
Supports 1 x RS232 console port(RJ45 type, Cisco Standard)
Supports 2 x USB 2.0 headers
Supports SSD, SATA HDD storage
Deploy Intel Intel H87 express chipset
Supports 2 x DDRIII SO DIMM memory, Max. 16GB
Integrated with 8*Intel 82574L GbE Ethernet cards, supports Wake On LAN, PXE booting
Supports 4 x GbE/10GbE SFP(optional)
Supports 1 x RS232 console port(RJ45 type, Cisco Standard)
Supports 2 x USB 2.0 headers
Supports SSD, SATA HDD storage
| Model No. | FWA-8781-4O | |
| Form Factor | 1U 19” Rackmount | |
| Platform | Processor Options | Intel Core i7/i5/i3, Pentium, Celeron, Xeon E3(Haswell) |
| CPU Socket | 1x LGA1150 | |
| Chipset | Intel H87 | |
| Security Acceleration | N/A | |
| BIOS | AMI SPI Flash BIOS | |
| System Memory | Technology | DDR3 1600/1333MHz |
| Max. Capacity | 16GB | |
| Socket | 2x 204pin SODIMM | |
| Networking | Ethernet Ports |
8x GbE RJ45 Intel 82583V/82574L 4x GbE SFP Intel 82580EB(Optional) |
| Bypass | Optional | |
| I/O Interface | Reset Button | - |
| LED | Power/Storage | |
| Power Button | 1x Power button | |
| Console | 1x RJ45 | |
| USB | 2x USB 2.0 | |
| LCD Module | - | |
| Display | 1x VGA | |
| Power Input | AC power inlet on PSU | |
| Storage | HDD/SSD Support |
2x 2.5'' bays or 1x 3.5'' bay |
| Onboard Storage | 1x m-SATA, 1X 2.5'' notebook SATA port | |
| Expansion | PCIe | 1x PCIe X8 |
| Mini-PCIe | Yes | |
| Miscellaneous | Watchdog | Yes |
| Internal RTC with Li Battery | Yes | |
| TPM | - | |
| Cooling | Processor | CPU fan |
| System | 3x cooling fans | |
| Environmental Parameters | Temperature | 0℃～45℃/ -20℃～70℃ |
| Humidity |
5 ~ 90% non condensing / 5 ~ 95%, non condensing |
|
| System Dimensions | (WxHxD) | 430x44.5x360mm |
| Weight | 4.5 kg | |
| Package Dimensions | (WxHxD) | 520x130x440mm |
| Weight | 5.2 kg | |
| Power | Type/Watts |
220W ATX Single PSU 300W Redundant PSU(Optional) |
| Input | 90~264V@47~63Hz | |
| Approvals and Compliance | CE, FCC Class B | |
-
