Model No.

EPC-N5242Z-V

Form Factor

Desktop

Platform

Processor Options

 Integrated In-tel Processor Celeron J4125 quad-core eight-thread processor, TDP 15W

CPU Socket

Onboard

Chipset

SoC

OS Support

Wi-dows 10,11,64bit,

U-buntu

BIOS

AMI BIOS

System Memory

Technology

DDR4

1 x DDR4 SODIMM slot, supporting 2400MHz memory and a maximum of 16GB memory

Max. Capacity

16GB

Socket

1 x SODIMM

Networking

Ethernet Ports

 1 x PS/2 interface, keyboard and mouse in one

2 x RJ45 Gigabit network port, 2 x Re-altek8111H

Storage

M.2

1*M.2 slot, 2280 Support SATA mode

M.2

1*M.2 slot M.2 2230, support WiFi

mSATA

-

Mini SAS

-

HDD/SSD Support

-

I/O Interface

LED

1 x PWR LED, 1 x HDD LED

Power Button

1 x Power Button

Console

1 x RJ45 Console

 Display

LAN

Reset Button

-

Display

1 x VGA port, 1 x H-DMI port

Power Input

DC 12V

Expansion

PCIe X1

1 x PCIe x1 slot

1 x Mini PCIe

1 x Mini PCIe slot

M.2

1*M.2 slot, 2280 Support SATA mode

1*M.2 slot M.2 2230, support WiFi

USB

4 x USB 3.0 interface

Miscellaneous

Watchdog

Support hardware reset function (256 levels, 0~255 seconds)

Internal RTC with Li Battery

Yes

TPM

-

Cooling

Processor

1 x CPU fan

System

1x Cooling fan

Environmental Parameters

Temperature

-10℃~60℃(Operating)/ -20℃~70℃(Storage)

Humidity

5 ~ 90% Non condensing

System Dimensions

(WxHxD)

Weight

1.55kg

Package Dimensions

(WxHxD)

Weight

Power

Type/Watts

AC TO DC, 36W / 60W (optional)

Input

90~264V @47~63Hz

Approvals and Compliance

CE, FCC, RoHS
