EPC-B263

Fanless heatsink structure
All aluminum chassis, compact structure and flexible installing
Support WIFI/3G module, providing onboard SIM expansion slot
1*VGA/1*HDMI
2 x Intel Gigabit Ethernet port supporting wake on LAN
I/O Interfaces:6xCOM,1xVGA,2xLan, 1xAduio, 4xUSB,1xHDMI

　　Designed with Intel® Atom N2600/N2800 processor and SoC chipset and 12VDC input to take a low power consumption advantage, EPC-B263 is a compact fanless industrial computing housed in a size of 182mm*107mm*63.5mm. The EPC-B263 supports five RS232, one RS232/485, two 10/100/1000 LAN port, six USB ports, one HDMI display, one VGA display and audio jack (speaker-out). It is also a wireless-ready platform which has Mini-PCIe socket and SIM card holder onBoard to support optional GSM wireless module or Wi-Fi module (default).
With isolation protection of 2,500VDC, and dry contact support, EPC-B263 can be applied to industrial and building automation applications. With rich IO connection in palm-sized system, EPC-B263 is an ideal fanless system for factory automation, machine automation, gate control, public information, self-service system, POS, Kiosk, low-power budget devices, transportation applications and self-service applications.
Fanless heatsink structure
All aluminum chassis, compact structure and flexible installing
Support WIFI/3G module, providing onboard SIM expansion slot
1*VGA/1*HDMI
2*RTL 8111E GbE port, support wake on LAN
I/O Interfaces:6xCOM,1xVGA,2xLan, 1xAduio, 6xUSB,1xHDMI
Model No. 　 EPC-B263
Processor System CPU Intel Atom N2600
Frequency 1.66GHz
Core Number 2C
Chipset Intel NM10
Fanless 　 Yes
Memory Technology DDR3 1333/1066 MHz
Max. Capacity 4GB
Socket 1x 204-pin SODIMM
Graphic Controller Intel HD 3600 Graphic
VGA 1920X1200@60HZ, 2x VGA
HDMI 1920X1200@60HZ
Audio Codec Realtek ALC662
Interface 1x Phone Jack for Line-out
Ethernet Controller Realtek RTL8111E
Speed 10/100/1000Mbps
Interface 2x RJ45
Storage Type SATAII
Installation 1 x m-SATA Socket
Type SATAII
Installation 1x 2.5” HDD/SSD Drive Bay
I/O Serial Port 6x RS232(COM2 supports RS485), DB9 Male
Digital I/O -
USB 2.0 6x Type A
USB 3.0 -
Power-On/Reset Button 1x Power On/Off, 1x Reset
Remote -
LED -
Antenna Hole 2x SMA Antenna Holes
Expansion Interface Mini PCIe 1x Full-sized Socket with SIM Card Reader(SIM socket available at I/O)
PCI -
PCI Express -
Watchdog Timer 　 Watchdog Timer 1~255 Level Time Interval
System Reset, Software Programmable
Power Power Type Desktop Power Adapter
Power Supply Voltage 12 VDC
Connector DC Jack
Power Adapter AC to DC, AC 90 to 240 VAC Input,
DC 12VDC /5A 60W
Environment Operating Temperature 00°C~45°C (with Industrial-grade Components)
Storage Temperature -20°C~70°C
Relative Humidity 5%~95%, Non-condensing
Vibration IEC 60068-2-64, 0.5Grms,
Random 5~500Hz, 40 Mins/Axis
Mechanical Dimension(W x H x D) 182x63.5x107mm
Construction Aluminum + SGCC
Weight 1.4kg
Mounting Wallmount
Driver Support Microsoft Windows Yes
Linux Yes
Certification EMC CE,FCC Class B
Ordering Information
Part number CPU LAN COM USB Wi-Fi Power
EPC-B263A Atom N2600 2 x RTL81111E 6 6 Optional 60W external adapter
EPC-B263B Atom N2800 2 x RTL81111E 6 6 Optional 60W external adapter
Packing List
1 Power cord 3P 180cm, China
2 60W external adapter
3 Driver CD
4 Accessory screw bag
Optional Accessories
1 Power cord 3P 180cm, USA
2 Power cord 3P 180cm, Europe
3 Power cord 3P 180cm, UK
4                     Power cord 3P 180cm, Japan
5 Power cord 3P 180cm, India
