1U Rackmount Network Appliance with Intel Core i3/i5/i7 or X_Armortec

Feature:

Adopts the dedicated multi Ethernet application scheme to design

Based on Intel Z87 express chipset

Integrated with 6 x Intel 82583V or 82574L 1000M Ethernet cards, supports 2 pairs BYPASS

Integrated 1 x Intel 82599 or i350, supporting 2 x 10GbE SFP ports

Provides 1 Mini PCIe slot, supports Wi-Fi/LTE modules

Provides 1 mSATA slot, supports SSD, transit rate reaches 6Gbps

Supports SSD, SATA HDD, CF card storage

	Chipset	Intel Z87
OS Support		Linux, Ubuntu, CentOS, pfSense, Windows All
BIOS		AMI 32M
System Memory	Technology	DDR3 1600/1333/1066MHz
	Max. Capacity	16GB
	Socket	2 x SO-DIMM
Networking	Ethernet Ports	6 x Intel 82583V/82574L GbE LAN 2 x GbE SFP via Intel i350 or 82599
	Bypass	1 pair of BYPASS
Storage	HDD Bays	1 x 3.5 inch, or 2 x 2.5 inch
	CF/SD	1 x CF socket onboard
	mSATA	1 x mSATA socket onboard
I/O Interface	Reset Button	1 x Reset Button
	LED	1 x Power LED, 1 x HDD LED
	Power Button	1 x Power Button
	Console	1 x RJ45 Console
	USB	2 x USB 2.0
	LCD Module	N/A
	Display	1 x VGA output
	Power Input	1 x AC Inlet
Expansion	PCIe	N/A
	Mini-PCIe	1 x Mini PCIe
Miscellaneous	Watchdog	Yes
	Internal RTC with Li Battery	Yes
	TPM	N/A
Cooling	Processor	1 x Bronze CPU Fan
	System	3 x 4020 System Fan
Environmental Parameters	Temperature	-15~60℃
	Humidity	0% ~ 95%, non condensing
Physical Dimensions	(WxHxD)	43027044mm
	Weight	4.5KG
Package Dimensions	(WxHxD)	530370150mm
	Weight	5.0KG
Power	Type/Watts	220W
	Input	4A 100-127V~ or 2A 200-240V~ 47-63Hz
Approvals and Compliance		CE, FCC
