1U Rackmount Network Appliance with Intel Skylake Core i3/i5
1U Rackmount Network Appliance with Intel Skylake Core i3/i5/i7/Pentium/Celeron with 6 GbE LAN, 2 GbE SFP supporting mSATA and Wi-Fi/LTE card
Thank you for choosing the FW-1161-2O . The system is powered by Intel Core Processors, codenamed Skylake, with the Intel H110/Z170/H170 Chipset. It supports up to 64GB of DDR4 system memory at 2133MT/s on dual-channel DIMM banks. The FW-7564-2O is equipped with advanced I/O capacity which includes an RJ-45 console port, 4 Serial-ATA ports (comply with SATA Standard 3.0 and 2.0), a mini SATA slot and a CompactFlash slot.
The onboard Ethernet ports be configured with bypass depending on the module specification.
The onboard Ethernet ports be configured with bypass depending on the module specification.
Adopts the dedicated multi Ethernet application scheme to design
Based on Intel H110/Z170/H170 chipset
Integrated with 6 x Intel I210/I211AT 1000M Ethernet cards, supports 3 pairs BYPASS
Integrated Intel Skylake Core i3/i5/i7/Pentium/Celero, supporting 2 x GbE SFP ports
Provides 1 Mini PCIe slot, supports Wi-Fi/LTE modules
Provides 1 mSATA slot, supports SSD, transit rate reaches 6Gbps
Supports SSD, SATA HDD, CF card storage
Based on Intel H110/Z170/H170 chipset
Integrated with 6 x Intel I210/I211AT 1000M Ethernet cards, supports 3 pairs BYPASS
Integrated Intel Skylake Core i3/i5/i7/Pentium/Celero, supporting 2 x GbE SFP ports
Provides 1 Mini PCIe slot, supports Wi-Fi/LTE modules
Provides 1 mSATA slot, supports SSD, transit rate reaches 6Gbps
Supports SSD, SATA HDD, CF card storage
| Model No. | FW-1161-2O | |
| Form Factor | 1U Rackmount | |
| Platform | Processor Options | Intel Skylake Core i3/i5/i7/Pentium/Celeron CPU |
| CPU Socket | LGA1151 | |
| Chipset | Intel H110/Z170/H170 | |
| OS Support | Linux, Ubuntu, CentOS, pfSense, Windows All | |
| BIOS | AMI 32M | |
| System Memory | Technology | DDR4 2133MT/s |
| Max. Capacity | 64GB | |
| Socket | 4x DIMM | |
| Networking | Ethernet Ports | 6 x Intel I210/I211AT GbE LAN 2 x GbE SFP |
| Bypass | 3 pair of BYPASS | |
| Storage | HDD Bays | 2 x 2.5 inch |
| CF/SD | 1 x CF socket onboard | |
| mSATA | 1 x mSATA socket onboard | |
| I/O Interface | Reset Button | N/A |
| LED | N/A | |
| Power Button | N/A | |
| Console | 1 x RJ45 Console | |
| USB | 2 x USB3.0 | |
| LCD Module | N/A | |
| Display | 1 x internal VGA inside the chassis | |
| Power Input | 1 x AC Inlet | |
| Expansion | PCIe | 1 x PCIe-X8 |
| Mini-PCIe | 1 x Mini PCIe | |
| Miscellaneous | Watchdog | Yes |
| Internal RTC with Li Battery | Yes | |
| TPM | Yes | |
| Cooling | Processor | 1 x Bronze CPU Fan |
| System | 3 x 4020 System Fan | |
| Environmental Parameters | Temperature | -10~60℃ |
| Humidity | 5~90%RH(25℃) | |
| Physical Dimensions | (WxHxD) | 428*298.5*44mm |
| Weight | 4.5KG | |
| Package Dimensions | (WxHxD) | 530*390*150mm |
| Weight | 5.0KG | |
| Power | Type/Watts | 220W |
| Input | 4A 100-127V~ or 2A 200-240V~ 47-63Hz | |
| Approvals and Compliance | CE, FCC | |
-
