Intel Xeon E3 1200, Core i3/i5/i7, Pentium and Celeron 1U Ra
Support 2nd/3rd Generation Intel Core i7/i5/i3 Quad/Dual-core CPU with B75 PCH (codenamed "Panther Point")
Entry-level 1U rackmount with 8 Intel GbE LAN ports
Shorter depth form factor design
Intel AES-NI, improves security without slowing response times
Supports up to 16 GB DDR3 memory
Intel 82583V LAN controller
3 x system cooling fans
Supports 2 groups LAN bypass
Optional front expansion slot
The FW-8010 is a short-depth 1U Rack mount network security system utilizing the cutting edge capabilities of the Intel Panther Point platform (Based on Intel Sandy Bridge / Ivy Bridge CPU and B75 PCH). The system includes Intel AES New Instruction (Intel AES-NI), allowing security algorithms to benefit from hardware acceleration for data encryption and decryption. It is targeted at UTM, firewall, VPN, IPS and WAN optimization applications for the small and medium business environment. The system has 8 Intel GbE LAN ports with LAN Bypass built-in, 2 DDR3 1600 DIMMs (Max. up to 16 GB), 3 system cooling fans and an ATX power supply.
Support 2nd/3rd Generation Intel Core i7/i5/i3 Quad/Dual-core CPU with B75 PCH (codenamed "Panther Point")
Entry-level 1U rackmount with 8 Intel GbE LAN ports
Shorter depth form factor design
Intel AES-NI, improves security without slowing response times
Supports up to 16 GB DDR3 memory
Intel 82583V LAN controller
3 x system cooling fans
Supports 2 groups LAN bypass
Optional front expansion slot
Entry-level 1U rackmount with 8 Intel GbE LAN ports
Shorter depth form factor design
Intel AES-NI, improves security without slowing response times
Supports up to 16 GB DDR3 memory
Intel 82583V LAN controller
3 x system cooling fans
Supports 2 groups LAN bypass
Optional front expansion slot
| Model No. | FW-8010 | |
| Form Factor | 1U Rackmount | |
| Platform | Processor Options | Intel Sandy Bridge/ Ivy Bridge Xeon E3 1200, Core i3/i5/i7, Pentium and Celeron |
| CPU Socket | LGA1155 | |
| Chipset | Intel B75 | |
| Security Acceleration | N/A | |
| BIOS | AMI BIOS | |
| System Memory | Technology | DDR3 1600/1333MHz |
| Max. Capacity | 16GB | |
| Socket | 2x 240pin DIMM | |
| Networking | Ethernet Ports | 8 x Intel Ethernet Controller GbE 82583V ports |
| Bypass | Optional | |
| I/O Interface | Reset Button | - |
| LED | Power LED x 1, HDD Active x 1, LAN LED x 12(Optoinal Status | |
| LED x 1) | ||
| Power Button | Power Button x 1(alternative to reset button) | |
| Console | 1x RJ45 | |
| USB | 2x USB 2.0 | |
| LCD Module | - | |
| Display | 1x VGA | |
| Power Input | AC power inlet on PSU | |
| Storage | HDD/SSD Support | 2x 2.5'' bays |
| Onboard Storage | 1x m-SATA, 1x CF(signal alternative to each other) | |
| Expansion | PCIe | - |
| Mini-PCIe | Yes | |
| Miscellaneous | Watchdog | Yes |
| Internal RTC with Li Battery | Yes | |
| TPM | - | |
| Cooling | Processor | CPU fan |
| System | 3x cooling fans | |
| Environmental Parameters | Temperature | 0℃～45℃/ -20℃～70℃ |
| Humidity | 5 ~ 90% non condensing | |
| System Dimensions | (WxHxD) | 428x43.9x300mm |
| Weight | 4.2 kg | |
| Package Dimensions | (WxHxD) | 530x150x390mm |
| Weight | 5.4 kg | |
| Power | Type/Watts | 220W 1U Flex ATX PSU |
| Input | 90~264V@47~63Hz | |
| Approvals and Compliance | CE, FCC Class B | |
-
