Intel Xeon 1U Rackmount 2 x GbE/10GbE SFP ports
Supports Intel LGA771 Xeon series dual core and quad core processors
Deploys Intel G41+ICH7R express chipset
Integrated with 6 Intel 82474L GbE Ethernet controller, supporting wake-on-LAN, PXE boot
Integrated 2 x Intel 82580DB GbE or Intel 82599ES 10 GbE SFP GbE
Reserves 1 3.5 inch/2.5 inch SATA bay inside the case, supporting RAID 0, 1, 5, 10
Supports 2 sets of BYPASS function, enabling the system to shift automatically into BYPASS or NORMAL status while encountered with power cutting off, hardware error or system crash.
Thank you for choosing the FWB-4161-2O. The system is powered by the newest Intel Xeon Processors, codenamed Harpertown, with the Intel G41 Series Chipset. It supports up to 8GB of DDR3 system memory at 1600MHz on dual-channel DIMM banks. The FWB-4161-2O is equipped with advanced I/O capacity which includes an RJ-45 console port, one PCIex8 (PCIe Generation 2.0) golden finger connected directly to the CPU for front expansion to 2 x GbE/10GbE SFP ports, 3 Serial-ATA ports (comply with SATA Standard 2.0), a mini SATA slot and a CompactFlash slot.
The onboard Ethernet ports be configured with bypass depending on the module specification.
The onboard Ethernet ports be configured with bypass depending on the module specification.
Supports Intel LGA771 Xeon series dual core and quad core processors
Deploys Intel G41+ICH7R express chipset
Integrated with 6 Intel 82474L GbE Ethernet controller, supporting wake-on-LAN, PXE boot
Integrated 2 x Intel 82580DB GbE or Intel 82599ES 10 GbE SFP GbE
Reserves 1 3.5 inch/2.5 inch SATA bay inside the case, supporting RAID 0, 1, 5, 10
Supports 2 sets of BYPASS function, enabling the system to shift automatically into BYPASS or NORMAL status while encountered with power cutting off, hardware error or system crash.
Deploys Intel G41+ICH7R express chipset
Integrated with 6 Intel 82474L GbE Ethernet controller, supporting wake-on-LAN, PXE boot
Integrated 2 x Intel 82580DB GbE or Intel 82599ES 10 GbE SFP GbE
Reserves 1 3.5 inch/2.5 inch SATA bay inside the case, supporting RAID 0, 1, 5, 10
Supports 2 sets of BYPASS function, enabling the system to shift automatically into BYPASS or NORMAL status while encountered with power cutting off, hardware error or system crash.
| Model No. | FWB-4161-2O | |
| Form Factor | 1U 19” Rackmount | |
| Platform | Processor Options | Intel Xeon |
| CPU Socket | 1x LGA771 | |
| Chipset | Intel G41+ICH7R | |
| Security Acceleration | N/A | |
| BIOS | AMI SPI Flash BIOS | |
| System Memory | Technology | DDR3 1600/1333MHz |
| Max. Capacity | 8GB | |
| Socket | 2x 204pin SODIMM | |
| Networking | Ethernet Ports | 6x GbE RJ45 Intel 82574L |
| 2x 10GbE SFP Intel 82599ES / GbE SFP NH82580DB | ||
| Bypass | Yes | |
| I/O Interface | Reset Button | - |
| LED | Power/Storage | |
| Power Button | 1x Power button | |
| Console | 1x RJ45 | |
| USB | 2x USB 2.0 | |
| LCD Module | - | |
| Display | 1x VGA | |
| Power Input | AC power inlet on PSU | |
| Storage | HDD/SSD Support | 2x 2.5'' bays or |
| 1x 3.5'' bay | ||
| Onboard Storage | 1x m-SATA, 1x CF, 1x IDE | |
| Expansion | PCIe | 1x PCIe X8 |
| Mini-PCIe | Yes | |
| Miscellaneous | Watchdog | Yes |
| Internal RTC with Li Battery | Yes | |
| TPM | - | |
| Cooling | Processor | CPU fan |
| System | 2x cooling fans | |
| Environmental Parameters | Temperature | 0℃～45℃/ -20℃～70℃ |
| Humidity | 5 ~ 90% non condensing / | |
| 5 ~ 95%, non condensing | ||
| System Dimensions | (WxHxD) | 430x44.5x380mm |
| Weight | 4.7 kg | |
| Package Dimensions | (WxHxD) | 520x130x460mm |
| Weight | 5.4 kg | |
| Power | Type/Watts | 220W ATX Single PSU |
| Input | 90~264V@47~63Hz | |
| Approvals and Compliance | CE, FCC Class B | |
-
