Form Factor

Desktop

Platform

Processor Options

Integrated I-ntel Skylake-U I3 5020U dual-core four-thread processor

CPU Socket

Onboard

Chipset

SoC

OS Support

OS: Wi-ndows 10/11;Lin-ux

BIOS

-

System Memory

Technology

2*DDR4 SODIMM memory slot,

support a maximum of 32GB memory

Max. Capacity

32 GB

Socket

Based on Intel Skylake-U SOC platform

Networking

Ethernet Ports

2*In-tel WGI211AT Gigabit LAN,Support Wake on LAN, PXE function

Storage

M.2

-

-

mSATA

1* MSATA SSD solid state drive expansion, transmission speed up to 6Gbps

Mini SAS

-

HDD/SSD Support

1*2.5 inch hard drive expansion

I/O Interface

LED

1*PWR LED, 1*HDD LED

Power Button

1*PWR , 1*RST

COM

2* RS232 DB9 serial interface, COM2 supports RS232/RS485 switch

 Display

Integrated I-ntel Iris Graphics 540 supports DirectX 12 OpenGL 4.5

LAN

2*In-tel WGI211AT Gigabit LAN,Support Wake on LAN, PXE function

Audio

1* Line out,1* MIC

Display port

1*VGA(1920X1200@60Hz),1*HDMI2.0 interface(4096X2304@60Hz),

1* DP interface(4096X2304@60Hz)

Power Input

DC 12V

Expansion

PCIe X1

-

1 x Mini PCIe

1* Mini PCIE slot, support WIFI/4G module

M.2

1* M.2, support M.2 2260/2280 NVME PCIE x4 standard SSD

USB

4 x USB 3.2 interface

Miscellaneous

OS

Wi-ndows 10,64bit, Li-nux Ubuntu

Internal RTC with Li Battery

Yes

TPM

-

Cooling fan

Processor

NO

System

NO

Environmental Parameters

Temperature

-10℃~60℃(Operating)/ -20℃~70℃(Storage)

Humidity

5 ~ 90% Non condensing

System Dimensions

(WxHxD)

 -

Weight

 -

Package Dimensions

(WxHxD)

 -

Weight

 -

Power

Type/Watts

-

Input

90~264V @47~63Hz

Approvals and Compliance

CE, FCC, RoHS
